BPH5B16HL1LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
BPH RoHS Compliant Keying Slot Gold Connector Header -541F -55C~125C 1.5A 16.0muin 0.41mum
PDF
/
Inventory: 3222
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole
Contact Shape Square
Insulation Material Thermoplastic, Glass Filled
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series BPH
Feature Keying Slot
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit, Solder
Connector Type Header
Number of Positions 16
Color Grey
Number of Rows 2
Capacitance -541F
Fastening Type Latch Lock/Eject Hooks, Long
Contact Finish - Mating Gold
Contact Type Male Pin
Current Rating (Amps) 1.5A
Pitch 2.54mm
Insulation Height 0.697 17.70mm
Style Board to Cable/Wire
Number of Positions Loaded All
Pitch - Mating 0.100 2.54mm
Insulation Color Gray
Row Spacing - Mating 0.100 (2.54mm)
Contact Length - Post 0.244 6.20mm
Shrouding Shrouded - 4 Wall
Contact Finish - Post Tin
Contact Length - Mating 0.232 5.90mm
Overall Contact Length 0.783 19.90mm
Dimensions
Contact Finish Thickness - Mating 16.0μin 0.41μm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
