641439-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 02P MTA156 PSTD CONN ASSY BLU
PDF
/
Inventory: 3039
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Contact Shape Square
Housing Material Nylon
Technical
Packaging Bulk
Published 2008
Series MTA-156
JESD-609 Code e0
Feature Closed End
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Plug
Number of Positions 2
Color Blue
Number of Rows 1
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Male Pin
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 2
Reference Standard UL, CSA
Contact Finish Tin-Lead
Reliability COMMERCIAL
Body Length or Diameter 0.468 inch
Shrouding Yes
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.487 inch
Operating Temperature (Min) -55°C
Housing Color White
Rated Current (Signal) 1A
Contact Resistance 7mOhm
Wire Gauge 26 AWG
Insulation Resistance 5000000000Ohm
ELV Non-Compliant
Termination Type IDC
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire/Cable Gauge 26 AWG
Cable Termination IDC
Wire Type Discrete or Ribbon Cable
Contact Design PREASSEM CONN
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Plating Thickness 80μin
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
