RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description FEED THRU LOOSE PIECE PKG. Free Hanging Rectangular Connector
PDF
/
Inventory: 1543
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line), Right Angle
Housing Material Nylon

Technical

Packaging Bulk
Published 2011
Series MTA-100
Feature Feed Through
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 5
Color White
Number of Rows 1
Additional Feature FEED THRU, LOOSE PIECE PKG.
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.100 2.54mm
Total Number of Contacts 5
Reference Standard UL, CSA
Contact Finish Gold
Voltage - Rated AC 250V
Reliability COMMERCIAL
Shrouding No
Rated Current (Signal) 5A
Contact Resistance 6mOhm
Wire Gauge 24 AWG
Body/Shell Style PLUG
ELV Non-Compliant
Termination Type IDC
Wire/Cable Type Discrete
Wire/Cable Gauge 24 AWG
Cable Termination IDC
Insertion Force-Max 8.896 N
Wire Type Discrete or Ribbon Cable
Contact Design PREASSEM CONN
Wire Size (Max) 22 AWG

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin

Compliance

RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
