5-641175-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 23POS IDC 22AWG GOLD
PDF
/
Buying Options
Total Price: USD $29.12
Unit Price: USD $29.117496
≥1 USD $29.117496
≥200 USD $11.617852
≥500 USD $11.230547
≥1000 USD $11.038863
Inventory: 1158
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 15.0μin 0.38μm
Width 9.779mm
Length 91.14mm
Height 9.779mm
Technical
Mating Alignment Without
Contact Retention With
Wire Type Discrete or Ribbon Cable
Insulation Diameter 2.41 mm
Mating Retention With
Circuit Application Signal
Contact Current Rating 7A
Sealable No
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 22 AWG
Operating Supply Voltage 600V
Housing Color Red, White
Number of Contacts 23
Shrouding No
Approval Agency CSA
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Pitch 0.156 3.96mm
Contact Type Female Socket
Voltage - Rated 600V
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Number of Positions 23
Connector Type Receptacle
Termination IDC
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Feed Through
Series MTA-156
Published 2008
Packaging Bulk
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin, Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 16 Weeks
