5-103955-1 image
Favorite
5-103955-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Headers & Wire Housings 10X2 MTE PIN SR RIBBED .100CL
PDF
/
Inventory: 3227
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 20 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)

Physical

Contact Material Bronze
Contact Plating Tin
Mount Cable, Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Thermoplastic

Technical

Packaging Tube
Published 2005
Series AMPMODU MTE
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC, IDT
Connector Type Plug
Number of Positions 2
Max Operating Temperature 105°C
Min Operating Temperature -65°C
Color Black
Number of Rows 1
Contact Type Male Pin
Pitch 0.100 2.54mm
Orientation Straight
Current Rating 3A
Contact Finish Gold
Approval Agency CSA
Number of Contacts 2
Contact Gender Male
Housing Color Black
Operating Supply Voltage 267V
Contact Resistance 15mOhm
Wire Gauge 26-30 AWG
Insulation Resistance 5GOhm
Row Spacing 2.54 mm
ELV Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Cable Termination IDC
Contact Current Rating 3A
Mating Retention Without
Wire Type Discrete

Dimensions

Height 2.49mm
Length 50.292mm
Contact Finish Thickness 30.0μin 0.76μm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
