4-641170-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 12P MTA156 ASSY 22AWG RED LF
PDF
/
Buying Options
Total Price: USD $13.45
Unit Price: USD $13.446722
≥1 USD $13.446722
≥250 USD $5.365822
≥500 USD $5.185955
≥1000 USD $5.097991
Inventory: 1138
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Tin, Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Underplate Material Nickel
Technical
Packaging Bulk
Published 2008
Series MTA-156
Feature Feed Through
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination IDC
Connector Type Receptacle
Number of Positions 12
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Red
Number of Rows 1
Voltage - Rated 600V
Fastening Type Locking Ramp
Contact Type Female Socket
Pitch 0.156 3.96mm
Current Rating 7A
Contact Finish Gold
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 12
Contact Gender Female
Housing Color Red, White
Operating Supply Voltage 600V
Wire Gauge 22 AWG
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Cable Termination IDC
Sealable No
Contact Current Rating 7A
Circuit Application Signal
Mating Retention With
Insulation Diameter 2.41 mm
Wire Type Discrete or Ribbon Cable
Contact Retention With
Mating Alignment Without
Dimensions
Height 9.779mm
Length 47.55mm
Width 9.779mm
Contact Finish Thickness 15.0μin 0.38μm
Plating Thickness 1.77μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
