3-644381-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 07P MTA156 QUAD ASSY W/TBS C/E
PDF
/
Inventory: 1890
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Technical
Packaging Bulk
Published 2008
Series MTA-156
JESD-609 Code e3
Feature Closed End, Polarizing Key
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Receptacle
Number of Positions 7
Color Black
Number of Rows 1
Additional Feature POLARIZED
HTS Code 8536.69.40.40
Fastening Type Locking Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.156 3.96mm
Total Number of Contacts 7
Reference Standard UL, CSA
Contact Finish Tin
Reliability COMMERCIAL
Shrouding No
Body Breadth 0.355 inch
Contact Gender Female
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 7A
Contact Resistance 3mOhm
Wire Gauge 18 AWG
Insulation Resistance 5000000000Ohm
ELV Compliant
Termination Type IDC
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 2200VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 18 AWG
Cable Termination IDC
Wire Type Discrete or Ribbon Cable
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
