3-643193-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 05P MTA156 CONN ASSY H/F 22AWG
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.59224
≥100 USD $0.589952
≥500 USD $0.570064
≥1000 USD $0.477928
≥3000 USD $0.448026
Inventory: 952
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 80μm
Contact Finish Thickness 80.0μin 2.03μm
Length 19.81mm
Height 9.02mm
Technical
Contact Retention With
Wire Type Discrete or Ribbon Cable
Number of Signal Positions 0
Insulation Diameter 2.413 mm
Number of Power Positions 5
Contact Current Rating 7A
Sealable No
Withdrawl Force-Min .8896 N
Cable Termination IDC
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Termination Type IDC
ELV Compliant
Wire Gauge 22 AWG
Rated Current (Signal) 7A
Operating Supply Voltage 600V
UL Flammability Code 94V-2
Contact Gender Female
Approval Agency CSA
Reliability COMMERCIAL
Voltage - Rated AC 600V
Contact Finish Tin
Current Rating 7A
Total Number of Contacts 5
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Number of Rows 1
Color Red
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed End
JESD-609 Code e3
Series MTA-156
Published 2008
Packaging Bulk
Physical
Underplate Material Nickel
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material PHOSPHOR BRONZE
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 16 Weeks
