3-641236-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 8POS IDC 26AWG GOLD
PDF
/
Inventory: 7806
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Technical
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 26 AWG
Wire/Cable Type Discrete
ELV Compliant
Wire Gauge 26 AWG
UL Flammability Code 94V-2
Shrouding No
Voltage - Rated AC 600V
Contact Finish Gold
Current Rating 7A
Total Number of Contacts 8
Pitch 0.156 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Color Blue
Number of Positions 8
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
JESD-609 Code e3
Series MTA-156
Published 2009
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY
