3-1473562-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN PLUG 8POS IDC ORANGE RITS
PDF
/
Buying Options
Total Price: USD $8.29
Unit Price: USD $8.2896
≥1 USD $8.2896
≥10 USD $7.22744
≥100 USD $7.037536
≥500 USD $6.84728
≥1000 USD $6.42884
≥3000 USD $6.390842
Inventory: 100
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 8.00μin 0.203μm
Width 5.05mm
Length 24.1mm
Height 18.4912mm
Technical
Preloaded Yes
Mating Alignment With
Contact Retention Without
Wire Type Discrete
Mating Retention With
Halogen Free Halogen Free
Contact Current Rating 3A
Sealable No
Cable Termination IDC
Wire/Cable Type Discrete
ELV Compliant
Housing Color Orange
Number of Contacts 8
Lead Pitch 2mm
Contact Finish Gold
Current Rating 3A
Shielding Unshielded
Orientation Straight
Pitch 0.079 2.00mm
Contact Type Male Pin
Fastening Type Latch Lock
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 167°C
Number of Positions 8
Connector Type Plug
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series RITS
Published 2003
Packaging Bulk
Physical
PCB Mount Retention Without
Housing Material Thermoplastic
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 18 Weeks
