2-102448-8
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings HSG DUAL 60P 22-20
PDF
/
Inventory: 7485
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material PBT
Technical
Packaging Tray
Published 2015
Series AMPMODU MT
Feature Closed End
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Connector Type Receptacle
Number of Positions 60
Color Black
Number of Rows 2
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 60
Contact Finish Gold
Contact Gender Female
Wire Gauge 20-22 AWG
Insulation Resistance 5GOhm
Row Spacing 0.100 (2.54mm)
ELV Non-Compliant
Wire/Cable Type Discrete
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 20 AWG
Cable Termination IDC
Contact Current Rating 3A
Wire Type Discrete or Ribbon Cable
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
