1318758-2 image
Favorite
1318758-2 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description Automotive Connectors 025/090 ECU PLUG HSG ASY 30P
PDF
/
Inventory: 1585
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Flammability Rating UL94 HB
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Width 29mm
Length 21.9964mm
Height 20.9042mm

Technical

Serviceable Yes
Polarized Yes
Hybrid Connector Yes
Mating Tab Width 2.286mm
Circuit Application Signal
ELV Compliant
Housing Color Black
Number of Contacts 30
Row Spacing - Mating 5.8928 mm
Depth 22mm
Orientation Straight
Pitch 2.2098mm
Fastening Type Ramp
Number of Rows 3
Color Black
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 30
Connector Type Plug, Socket
Termination Crimp
Packaging Bulk

Physical

Body Material PBT
Housing Material Polybutylene
Mount Free Hanging

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 4 days ago)
