111446-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN IDC PIN 26POS 30AU NO LATCH
PDF
/
Inventory: 2018
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material Bronze
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Plastic
Technical
Packaging Tray
Published 2011
Series AMP-Latch
JESD-609 Code e0
Feature Feed Through
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Number of Positions 26
Color Black
Number of Rows 2
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Contact Type Male Pin
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Reach Compliance Code unknown
Contact Finish Gold
Wire Gauge 26-28 AWG
Row Spacing 0.100 (2.54mm)
ELV Non-Compliant
Wire/Cable Type Ribbon
Wire Gauge (Max) 28 AWG
Wire Gauge (Min) 26 AWG
Cable Termination IDC
Wire Type Ribbon Cable
Dimensions
Height 19.2mm
Length 47.5mm
Width 8.38mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
