103956-1
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RECPT 2POS .100 P0LAR TIN
PDF
/
Buying Options
Total Price: USD $1.39
Unit Price: USD $1.3904
≥1 USD $1.3904
≥10 USD $1.21176
≥100 USD $1.15984
≥500 USD $1.134144
≥1000 USD $1.082558
≥3000 USD $0.979466
Inventory: 4164
Minimum: 1
-
+
Technical Details
Technical
Operating Supply Voltage 267V
Contact Resistance 15mOhm
Wire Gauge 22-26 AWG
Insulation Resistance 5GOhm
Row Spacing 2.54 mm
Inductance 1000 μH
ELV Non-Compliant
Test Frequency 0.79MHz
DC Resistance (DCR) 30Ohm
Wire/Cable Type Ribbon
Wire Gauge (Max) 22 AWG
Wire Gauge (Min) 26 AWG
Inductor Application HIGH CURRENT INDUCTOR
Wire/Cable Gauge 22 AWG
Terminal Placement AXIAL
Cable Termination IDC
Quality Factor-Min (at L-nom) 85
Contact Current Rating 3A
Inductor Type GENERAL PURPOSE INDUCTOR
Mating Retention With
Insulation Diameter 1.37 mm
Wire Type Discrete
Contact Gender Female
Approval Agency CSA
Contact Finish Tin-Lead
Current Rating 3A
Depth 15.24mm
Number of Functions 1
Shielding NO
Orientation Straight
Pitch 0.100 2.54mm
Contact Type Female Socket
Fastening Type Latch Lock
HTS Code 8504.50.80.00
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 2
Connector Type Receptacle
ECCN Code EAR99
Termination IDC, IDT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 10%
Series AMPMODU MTE
Published 2008
Packaging Tube
Self Resonant Frequency 3MHz
Physical
Shape/Size Description TUBULAR PACKAGE
Housing Material Thermoplastic
Terminal Shape PRINTED WIRING PIN
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Plating Tin
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 20 Weeks
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness 100.0μin 2.54μm
Length 50.8mm
Height 5.08mm
