1-353293-8
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
CONN RCPT 18POS IDC 26-28AWG TIN
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.41976
≥100 USD $0.417472
≥500 USD $0.403392
≥1000 USD $0.338272
≥3000 USD $0.317152
Inventory: 6454
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length 28.5mm
Technical
Insulation Diameter-Min 0.032 inch
Wire Type Discrete
Mating Retention With
Sealable No
Insertion Force-Max 4.0032 N
Cable Termination IDC
Max Voltage Rating (DC) 5.05kV
Durability 30 Cycles
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Dielectric Withstanding Voltage 500VAC V
Polarization Key POLARIZED HOUSING
Max Voltage Rating (AC) 50V
ELV Compliant
Wire Gauge 26-28 AWG
Contact Resistance 20mOhm
Rated Current (Signal) 2A
Housing Color Natural
UL Flammability Code 94V-0
Contact Gender Female
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL
Current Rating 2A
Depth 6mm
Orientation Straight
Total Number of Contacts 18
Pitch 0.059 1.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Voltage - Rated 50V
Number of Rows 1
Color Gray
Min Operating Temperature -30°C
Max Operating Temperature 105°C
Number of Positions 18
Connector Type Receptacle
ECCN Code EAR99
Termination IDC, IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed End
Series Mini CT
Published 1999
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Cable, Free Hanging
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 25 Weeks
