647478-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 06P MTA156 CONN ASSY 22AWG RED
PDF
/
Inventory: 7615
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 9.02mm
Length 23.8mm
Height 18.4mm
Technical
Withdrawl Force-Min .4448 N
Insertion Force-Max 5.7824 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 22 AWG
Durability 25 Cycles
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Contact Resistance 3mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 7A
Body Depth 0.725 inch
Housing Color Red, White
UL Flammability Code 94V-2
Operating Temperature (Min) -55°C
Contact Gender Female
Body Breadth 0.355 inch
Number of Contacts 6
Shrouding Yes
Reliability COMMERCIAL
Reference Standard UL, CSA
Pitch 3.96mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
Additional Feature POLARIZATION AVAILABLE
Number of Rows 1
Color Red
Connector Type Connector, Receptacle, Socket
ECCN Code EAR99
Termination Crimp
JESD-609 Code e0
Packaging Bulk
Physical
Housing Material Nylon
Contact Shape Square
Mount Free Hanging
Contact Plating Gold
Contact Material COPPER ALLOY
