640608-2
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 4896
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
Termination IDC
Connector Type Connector, Receptacle, Socket
Number of Positions 2
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Blue
Number of Rows 1
Pitch 3.9624mm
Orientation Right Angle
Current Rating 7A
Voltage - Rated AC 600V
Approval Agency CSA
Shrouding No
Number of Contacts 2
Contact Gender Female
Housing Color Blue, White
Contact Resistance 3mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Wire/Cable Type Discrete
Wire/Cable Gauge 26 AWG
Insulation Diameter 2.41 mm
Contact Rating (Current) 7A
Dimensions
Height 9.779mm
Length 7.92mm
Plating Thickness 5.08μm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
