TCSD-11-01-F-N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Tiger Eye? TCSD ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 105C 0.157inch
PDF
/
Buying Options
Total Price: USD $15.23
Unit Price: USD $15.227014
≥1 USD $15.227014
≥198 USD $6.076101
≥506 USD $5.872602
≥990 USD $5.772821
Inventory: 1099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material BERYLLIUM COPPER
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYESTER
Mounting Option 1 LOCKING
Technical
Packaging Tube
Published 2016
Series Tiger Eye? TCSD
Feature Feed Through, Polarizing Key
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination IDT
Connector Type Receptacle
Number of Positions 22
Color Black
Number of Rows 2
Gender Female
Fastening Type Push-Pull
Subcategory Headers and Edge Type Connectors
Contact Type Female Socket
Pitch 0.079 2.00mm
Total Number of Contacts 22
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Max) 105°C
Body Breadth 0.157 inch
Operating Temperature (Min) -40°C
Wire Gauge 28 AWG
Row Spacing 0.079 (2.00mm)
Polarization Key POLARIZED HOUSING
Cable Termination IDC
Wire Type Ribbon Cable
Contact Design PREASSEM CONN
Dimensions
Contact Finish Thickness Flash
Compliance
RoHS Status ROHS3 Compliant
