TCSD-05-01-F
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Tiger Eye? TCSD ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector -40C 0.157inch
PDF
/
Inventory: 7163
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Contact Finish Thickness Flash
Technical
Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Polarization Key POLARIZED HOUSING
Row Spacing 0.079 (2.00mm)
Wire Gauge 28 AWG
Operating Temperature (Min) -40°C
Body Breadth 0.157 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 10
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Fastening Type Push-Pull
Gender Female
Number of Rows 2
Color Black
Number of Positions 10
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Feed Through
JESD-609 Code e4
Series Tiger Eye? TCSD
Packaging Tube
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYESTER
Mounting Type Free Hanging (In-Line)
Contact Material BERYLLIUM COPPER
Supply Chain
Factory Lead Time 3 Weeks
