87568-5091
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings IDT DUAL RECPT 50P cable-to-board
PDF
/
Inventory: 5574
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Plating Thickness 15μin
Technical
Glow Wire Compliant Non-compliant
Insertion Force-Max 1.946 N
Contact Pattern RECTANGULAR
Wire/Cable Gauge 28 AWG
Durability 600 Cycles
Wire/Cable Type Ribbon
Polarization Key POLARIZED KEY
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 1A
Body Depth 0.449 inch
UL Flammability Code 94V-0
Contact Gender Female
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
Row Spacing - Mating 2.0066 mm
Reliability COMMERCIAL
Reference Standard UL
Current Rating 1A
Reach Compliance Code unknown
Total Number of Contacts 50
Pitch 2.0066mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Fastening Type Ramp
HTS Code 8536.69.40.40
Additional Feature POLARISED
Voltage - Rated 125V
Number of Rows 2
Color Black
Number of Positions 50
Connector Type IDC, Receptacle, Socket
ECCN Code EAR99
Termination IDC
Part Status Discontinued
Published 2005
Physical
Housing Material Thermoplastic
Mount Free Hanging
Contact Plating Gold
Contact Material NOT SPECIFIED
