39170-1026

Molex
RoHS
/
Package Module
Category Connectors, Interconnects / Terminal Blocks - Interface Modules
Description Terminal Block Interface Modules 26 pin Ribbon Cable One-Piece Fixed
PDF
/
Inventory: 4257
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Tin
Mounting Type BOARD
Package / Case Module
Housing Material Polyamide

Technical

Packaging Bulk
Published 2007
Part Status Discontinued
ECCN Code EAR99
Number of Positions 26
Color Black
Number of Rows 2
Voltage - Rated 300V
Additional Feature POLARIZED, SHROUDED
HTS Code 8536.69.40.40
Pitch 5.08mm
Orientation Vertical
Reach Compliance Code unknown
Current Rating 15A
Insulation Resistance 5GOhm
Wire Gauge (Max) 26 AWG
Wire Gauge (Min) 26 AWG
Number of Decks 2
Terminal and Terminal Block Type BARRIER STRIP TERMINAL BLOCK
Number of Ways 26
Contact Rating (Current) 15A
Fastening Method SCREW

Dimensions

Length 76.2mm
Width 92.456mm

Compliance

RoHS Status RoHS Compliant
