RL01S-P16S-C36BE

JAE Electronics
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description RL01/RL01S/RL02S RoHS Compliant 2004 Lead Free Plug Rectangular Connector 30AWG Flash
PDF
/
Inventory: 8729
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)

Technical

Packaging Tray
Published 2004
Series RL01/RL01S/RL02S
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Plug
Number of Positions 16
Color Black
Number of Rows 1
Contact Type Male Pin
Pitch 0.031 0.80mm
Contact Finish Gold
Wire Gauge 26-30 AWG
Wire/Cable Type Discrete
Wire Gauge (Max) 30 AWG
Wire Gauge (Min) 26 AWG
Cable Termination Solder
Wire Type Discrete

Dimensions

Contact Finish Thickness Flash

Compliance

RoHS Status RoHS Compliant
Lead Free Lead Free
