M80-5C12605B1

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description CONN HEADER 26POS CRIMP 24-28AWG
PDF
/
Inventory: 4752
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Plating Thickness 30μin
Contact Finish Thickness 29.5μin 0.75μm

Technical

Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 28 AWG
Polarization Key POLARIZED HOUSING
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 24-28 AWG
Rated Current (Signal) 3A
Body Depth 0.393 inch
UL Flammability Code 94V-0
Contact Gender Male
Body Breadth 0.311 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Current Rating 3A
Total Number of Contacts 26
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Male Pin
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Voltage - Rated 120V
Number of Rows 2
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 121°C
Number of Positions 26
Connector Type Header
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Jackscrews, Shielded
Series Datamate S-Tek
Published 2010
Packaging Bulk

Physical

Housing Material Polyphenylene
Mounting Type Panel Mount
Mount Panel
Contact Material Brass
