M80-4E11242F1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate J-Tek ROHS3Compliant 2012 GENERAL PURPOSE Receptacle Rectangular Connector 32AWG 11.8muin 0.30mum
PDF
/
Inventory: 1991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Technical
Wire Type Discrete
Cable Termination Crimp
Wire Gauge (Min) 28 AWG
Wire Gauge (Max) 32 AWG
Row Spacing 0.079 (2.00mm)
Wire Gauge 28-32 AWG
UL Flammability Code 94V-0
Contact Finish Gold
Total Number of Contacts 12
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Female Socket
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Black
Number of Positions 12
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Jackscrews
JESD-609 Code e3
Series Datamate J-Tek
Published 2012
Packaging Bulk
Physical
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material NOT SPECIFIED
Supply Chain
Factory Lead Time 9 Weeks
