M80-4000000FG-03-306-00-000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Datamate Mix-Tek ROHS3Compliant COMMERCIAL UL Receptacle Rectangular Connector 500Cycles 8.0064N 6mOhm -55C
PDF
/
Inventory: 8618
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Filter Feature NO
Contact Type Female Socket, Coaxial
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.157 4.00mm
Total Number of Contacts 3
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.866 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Body Depth 0.297 inch
Contact Resistance 6mOhm
Durability 500 Cycles
Cable Termination Crimp
Insertion Force-Max 8.0064 N
Wire Type Coaxial
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Color Black
Number of Positions 3
Connector Type Receptacle
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Jackscrews
Series Datamate Mix-Tek
Published 2015
Packaging Bulk
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Option 1 LOCKING
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Panel Mount
Contact Material NOT SPECIFIED
