AWH 60G-E232-IDC

Assmann WSW Components
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description Rectangular Connector Panel Mount
PDF
/
Inventory: 2234
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Plating Thickness 100μin

Technical

Contact Design PREASSEM CONN
Wire Type Ribbon Cable
Cable Termination IDC
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
Termination Type IDC
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5000000000Ohm
Rated Current (Signal) 3A
Body Depth 0.756 inch
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Body Length or Diameter 3.767 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 60
Pitch 0.100 2.54mm
Contact Type Male Pin
Fastening Type Latch Lock/Eject Hooks, Long
Number of Rows 2
Color Gray
Number of Positions 60
Connector Type Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Feed Through
Packaging Tray

Physical

Mounting Option 2 LOCKING
Mounting Type Panel Mount
Contact Material COPPER ALLOY

Supply Chain

Factory Lead Time 23 Weeks
