776491-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 14-18AWG GOLD CRIMP
PDF
/
Buying Options
Total Price: USD $0.73
Unit Price: USD $0.7304
≥1 USD $0.7304
≥10 USD $0.70048
≥100 USD $0.669504
≥500 USD $0.660352
≥1000 USD $0.577016
≥3000 USD $0.555386
Inventory: 1367
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Contact Plating Gold, Tin
Mount Cable
Technical
Packaging Tape & Reel (TR)
Published 2008
Series AMPSEAL 16 HDSF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Connector, Power, Socket
Type Stamped
Max Operating Temperature 248°C
Min Operating Temperature -40°C
Gender Female
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Orientation Straight
Shielding Shielded
Depth 3.5mm
Contact Finish Gold
Wire Gauge 14-18 AWG
ELV Compliant
Wire Gauge (Max) 18 AWG
Wire Gauge (Min) 14 AWG
Wire/Cable Gauge 18 AWG
Sealable No
Contact Termination Crimp
Insulation Diameter 3.937 mm
Rated Current 13A
Pin or Socket Socket
Assembly Item Name CONTACT
Cable Entry-Max 0.155 inch
Cable Entry-Min 0.077 inch
Dimensions
Height 3.68mm
Length 18.33mm
Contact Finish Thickness 30.0μin 0.76μm
Compliance
RoHS Status RoHS Compliant
