776001-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Automotive Connectors RCPT TERMI-1.5MM OBD CONN
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1584
≥1 USD $0.1584
≥10 USD $0.13464
≥100 USD $0.13376
≥500 USD $0.132176
≥1000 USD $0.122144
≥3000 USD $0.10039
Inventory: 131772
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Length 15.7mm
Height 3.5mm

Technical

Cable Entry-Min 0.043 inch
Cable Entry-Max 0.088 inch
Mating Tab Width 1.5mm
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.2352 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 10A
ELV Compliant
Wire Gauge 18-22 AWG
Contact Finish Tin
Depth 3.5mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Female
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Number of Positions 1
Connector Type Connector, Crimp, Power, Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2006
Packaging Tape & Reel (TR)

Physical

Mount Cable
Contact Material Brass

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 13 Weeks
