61117-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 14-20AWG MNL
PDF
/
Buying Options
Total Price: USD $1.28
Unit Price: USD $1.2848
≥1 USD $1.2848
≥10 USD $1.17656
≥100 USD $1.141536
≥500 USD $1.130096
≥1000 USD $1.048872
≥3000 USD $1.031536
Inventory: 18955
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Dimensions
Plating Thickness 760 nm
Contact Finish Thickness 30.0μin 0.76μm
Length 17.9mm
Height 4.52mm
Technical
Cable Entry-Max 0.13 inch
VDE Tested No
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 3.302 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 15A
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 20 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 15A
ELV Compliant
Wire Gauge 14-20 AWG
Operating Supply Voltage 250V
Contact Gender Female
Contact Finish Gold
Current Rating 13A
Depth 4.32mm
Shielding Unshielded
Orientation Straight
Pitch 5.08mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)
Physical
Underplate Material Nickel
Contact Shape Round
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 7 Weeks
