175269-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
Contact SKT Crimp ST Cable Mount Strip
PDF
/
Buying Options
Total Price: USD $0.11
Unit Price: USD $0.1144
≥1 USD $0.1144
≥10 USD $0.09328
≥100 USD $0.077704
≥500 USD $0.059814
≥1000 USD $0.054155
≥3000 USD $0.047608
Inventory: 1294
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Tab Thickness 640μm
Length 15.9mm
Height 3.2mm
Technical
Design Use POWER
Cable Entry-Min 0.071 inch
Cable Entry-Max 0.102 inch
Mating Tab Width 1.8034mm
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.5908 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 16 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 20 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Wire Gauge 16-20 AWG
Contact Finish Tin
Depth 3.5mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Receptacle
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Connector Type Connector, PCB, Signal, Socket
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multi-Lock
Published 1997
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 4 Weeks
