175265-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONTACT, RECEPTACLE, 22-18AWG, CRIMP
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.176
≥1 USD $0.176
≥10 USD $0.14608
≥100 USD $0.135872
≥500 USD $0.128832
≥1000 USD $0.12188
≥3000 USD $0.113485
Inventory: 20665
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Tab Thickness 640μm
Length 15.9mm
Height 3.45mm
Technical
Design Use POWER
Cable Entry-Min 0.043 inch
Cable Entry-Max 0.083 inch
Mating Tab Width 990.6μm
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.1 mm
Contact Termination Crimp
Sealable No
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 18 AWG
Wire Gauge (Max) 22 AWG
Connector Support Type CONNECTOR ACCESSORY
ELV Compliant
Wire Gauge 18-22 AWG
Contact Resistance 20mOhm
Contact Finish Tin
Depth 2.5mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Receptacle
Min Operating Temperature -22°C
Max Operating Temperature 221°C
Number of Positions 1
Connector Type Connector, PCB, Signal
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Multi-Lock
Published 1997
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 4 Weeks
