102920-1 image
Favorite
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description Headers & Wire Housings 30P MODIV RECPT REEL
PDF
/
Buying Options
Total Price: USD $0.49
Unit Price: USD $0.492152
≥1 USD $0.492152
≥10 USD $0.464302
≥100 USD $0.438009
≥500 USD $0.413221
≥1000 USD $0.38983
Inventory: 6284
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 22 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)

Physical

Contact Material Bronze, Copper, Tin
Mounting Style STRAIGHT

Technical

Packaging Tape & Reel (TR)
Published 2006
Series AMPMODU Mod IV 1/2
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Operating Temperature 105°C
Min Operating Temperature -65°C
HTS Code 8536.90.40.00
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Pitch 2.54mm
Current Rating 3A
Voltage - Rated AC 250V
Approval Agency CSA
Contact Gender Female
Operating Supply Voltage 250V
Contact Resistance 12mOhm
Wire Gauge 27-32 AWG
Insulation Resistance 5GOhm
ELV Non-Compliant
Plating Gold
Connector Support Type CONNECTOR ACCESSORY
Wire/Cable Type Discrete
Wire Gauge (Max) 32 AWG
Wire Gauge (Min) 27 AWG
Wire/Cable Gauge 27 AWG
Contact Current Rating 3A
Contact Termination Crimp
Insulation Diameter 1.016 mm
Pin or Socket Socket
Assembly Item Name CONTACT
Design Use POWER AND SIGNAL

Dimensions

Contact Finish Thickness 30.0μin 0.76μm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Not Applicable
