05-02-0050
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
TERMINAL, 1.0-1.5MM
PDF
/
Inventory: 6324
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width - Tab 5.1mm
Length 14.99mm
Height 4.7mm
Technical
Used With 1461 SERIES HOUSING
Cable Entry-Min 0.061 inch
Cable Entry-Max 0.102 inch
Wire Size (Max) 18 AWG
Wire Size (Min) 22 AWG
Assembly Item Name CONTACT
Contact Design LOOSE
Wire/Cable Diameter 2.59 mm
Wire/Cable Gauge 14 AWG
Wire Gauge (Min) 14 AWG
Wire Gauge (Max) 16 AWG
Connector Support Type CONNECTOR ACCESSORY
Depth 5.3mm
Shielding Unshielded
Orientation Straight
Pitch 2.54mm
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Additional Feature CONTACT FINISH: TIN
Gender Receptacle
Connector Type Connector, Crimp, PCB, Signal
ECCN Code EAR99
Termination Crimp
Packaging Bulk
Physical
Mount Cable
Contact Plating Gold
Contact Material Brass
