7-146464-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HEADER 23POS .100 STACKER
PDF
/
Inventory: 6638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 10.16mm
Length - Tail 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Post (Mating) 0.087 2.210mm
Length - Overall Pin 0.817 20.752mm
Length - Stack Height 0.400 10.160mm
Length 20.7518mm
Technical
Stackable Yes
Mating Post Length 8.38mm
Contact Current Rating 3A
ELV Compliant
Insulation Resistance 5GOhm
Contact Finish - Post (Mating) Gold
Lead Length 20.75mm
Housing Color Black
Number of Contacts 23
Approval Agency CSA
Orientation Vertical
Pitch 0.100 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 23
Connector Type Header, Pin, Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod II
Published 2014
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 8 Weeks
