6-146456-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 14 MODII HDR SRST UNSHRD STKG
PDF
/
Inventory: 5378
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 6.35mm
Length - Tail 0.110 2.800mm
Contact Finish Thickness - Post (Mating) 100.0μin 2.54μm
Length - Post (Mating) 0.080 2.032mm
Length - Overall Pin 0.440 11.176mm
Length - Stack Height 0.250 6.350mm
Length 11.176mm
Technical
Stackable Yes
Mating Post Length 2.7686mm
Contact Current Rating 3A
ELV Compliant
Insulation Resistance 5GOhm
Contact Finish - Post (Mating) Tin
Lead Length 11.18mm
Housing Color Black
Number of Contacts 14
Approval Agency CSA
Current Rating 3A
Orientation Vertical
Pitch 0.100 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Number of Positions 14
Connector Type Header, Pin, Plug
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series AMPMODU Mod II
Published 2012
Packaging Bulk
Physical
PCB Mounting Orientation Vertical
Housing Material Thermoplastic
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 8 Weeks
