7-146477-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 6112
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 27.94mm
Length - Tail 3.048mm
Length 33.782mm
Technical
Mating Post Length 2.79mm
ELV Compliant
Lead Length 33.78mm
Housing Color Black
Number of Contacts 25
Approval Agency CSA, UL
Current Rating 3A
Orientation Vertical
Pitch 2.54mm
Number of Rows 1
Color Black
Min Operating Temperature -65°C
Max Operating Temperature -125°C
Number of Positions 25
Connector Type Header, Pin, Plug
Termination Solder
Packaging Bulk
Physical
Housing Material Thermoplastic
Contact Shape Square
Mount Through Hole
Contact Plating Tin
Contact Material Brass
