FW-14-04-G-D-320-075
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
LOW PROFILE Rectangular Connector Board Spacer
PDF
/
Inventory: 3292
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Bulk
Series Flex Stack, FW
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 28
Color Black
Number of Rows 2
Gender Male
Additional Feature LOW PROFILE
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 28
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Finish - Post (Mating) Gold
Row Spacing 0.050 (1.27mm)
Dimensions
Length - Stack Height 0.320 8.128mm
Length - Overall Pin 0.485 12.319mm
Length - Post (Mating) 0.075 1.905mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.090 2.286mm
Compliance
RoHS Status ROHS3 Compliant
