15-06-0141
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Housings
Description
CONN RECEPT 14POS W/PANEL MOUNT
PDF
/
Buying Options
Total Price: USD $2.41
Unit Price: USD $2.405138
≥1 USD $2.405138
≥10 USD $2.268996
≥100 USD $2.140566
≥500 USD $2.019399
≥1000 USD $1.905093
Inventory: 7294
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 17.3mm
Length 61.2mm
Technical
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Withdrawl Force-Min .5004 N
Max Voltage Rating (DC) 600.6kV
Max Voltage Rating (AC) 600V
Insulation Resistance 1000000000Ohm
Contact Resistance 10mOhm
Contact Style SQ PIN-SKT
Empty Shell NO
UL Flammability Code 94V-0
Contact Gender Female
Body Breadth 0.681 inch
Number of Contacts 14
Row Spacing - Mating 4.191 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 13A
Depth 19.6mm
Orientation Straight
Pitch 4.2mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.30
Additional Feature MINI-FIT
Gender Receptacle
Number of Rows 2
Color Natural
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Receptacle, Socket
ECCN Code EAR99
Termination Crimp
Part Status Active
Pbfree Code yes
Published 2008
Physical
Housing Material Nylon
Shell Material POLYAMIDE66
Mount Panel
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 9 Weeks
