FW-08-03-F-D-150-075
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 16 POS 1.27mm Solder ST SMD Tube
PDF
/
Inventory: 2507
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material Bronze
Mounting Type Surface Mount
Housing Material Polymer
Technical
Packaging Tube
Series Flex Stack, FW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 16
Orientation Straight
Depth 3.42mm
Contact Finish - Post (Mating) Gold
Row Spacing 0.050 (1.27mm)
Dimensions
Length 10.16mm
Length - Stack Height 0.150 3.810mm
Length - Overall Pin 0.225 5.715mm
Length - Post (Mating) 0.075 1.905mm
Contact Finish Thickness - Post (Mating) 3.00μin 0.076μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
