EW-23-09-T-D-300
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 46POS 0.1 STACK T/H TIN
PDF
/
Inventory: 4212
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.330 8.382mm
Length - Post (Mating) 0.100 2.540mm
Length - Overall Pin 0.730 18.542mm
Length - Stack Height 0.300 7.620mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Tin
UL Flammability Code 94V-0
Contact Gender MALE
Total Number of Contacts 46
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Number of Positions 46
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
JESD-609 Code e3
Series Flex Stack, EW
Packaging Bulk
Physical
Mounting Type Through Hole
Supply Chain
Factory Lead Time 3 Weeks
