EW-16-09-L-S-200

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Board Spacer
PDF
/
Inventory: 6425
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length - Tail 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.200 5.080mm
Length - Overall Pin 0.730 18.542mm
Length - Stack Height 0.200 5.080mm

Technical

Contact Finish - Post (Mating) Gold
UL Flammability Code 94V-0
Contact Gender MALE
Total Number of Contacts 16
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Color Black
Number of Positions 16
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, EW
Published 2013
Packaging Bulk

Physical

Mounting Type Through Hole
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 3 Weeks
