DWM-30-61-S-D-740
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Conn Board Stacker HDR 60 POS 1.27mm Solder ST Thru-Hole Tube
PDF
/
Buying Options
Total Price: USD $14.45
Unit Price: USD $14.445568
≥1 USD $14.445568
≥10 USD $13.627893
≥100 USD $12.856502
≥500 USD $12.128778
≥1000 USD $11.442245
Inventory: 7807
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Tube
Series Flex Stack, DWM
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 60
Color Black
Number of Rows 2
Gender Male
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.050 1.27mm
Total Number of Contacts 60
Contact Finish - Post (Mating) Gold
Row Spacing 0.100 (2.54mm)
Dimensions
Length - Stack Height 0.740 18.796mm
Length - Overall Pin 1.050 26.670mm
Length - Post (Mating) 0.190 4.826mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Tail 0.120 3.048mm
Compliance
RoHS Status ROHS3 Compliant
