M22-2662546
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 25+25 DIL EXT P/HDR 6MM BOARD STK HT
PDF
/
Inventory: 5828
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type Through Hole
Insulation Material NYLON
Technical
Packaging Bulk
Series M22
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type BOARD CONNECTOR
Number of Positions 50
Color Black
Number of Rows 2
Additional Feature ROHS COMPLIANT
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 50
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 1.969 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Body Breadth 0.157 inch
Contact Gender MALE
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 1A
Contact Finish - Post (Mating) Gold
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style RECEPTACLE
Contact Pattern RECTANGULAR
Dimensions
Length - Stack Height 0.236 6.000mm
Length - Overall Pin 0.469 11.900mm
Length - Post (Mating) 0.138 3.500mm
Length - Termination 0.094 inch
Length - Tail 0.094 2.400mm
Compliance
RoHS Status ROHS3 Compliant
