09170289622
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
PLUG, DIL IDC 28WAY - More Details
PDF
/
Buying Options
Total Price: USD $5.46
Unit Price: USD $5.4648
≥1 USD $5.4648
≥10 USD $4.93768
≥100 USD $4.664387
≥500 USD $4.550674
≥1000 USD $4.32315
≥3000 USD $3.868058
Inventory: 56
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Copper
Contact Plating Gold
Mount Cable, Through Hole
Mounting Type Through Hole
Material Thermoplastic
Technical
Packaging Bulk
Series SEK
Feature Feed Through
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
ECCN Code EAR99
Connector Type Ribbon Cable, DIP Header
Number of Positions 28
Color Beige
Number of Rows 2
Gender Male
Additional Feature SOLDERED DIRECTLY TO THE BOARD
HTS Code 8536.69.40.51
Subcategory Headers and Edge Type Connectors
Voltage - Rated DC 250V
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 28
Orientation Right Angle
Depth 18.7mm
Number of Positions Loaded All
Current Rating 2A
Number of Conductors ONE
Reference Standard UL
Contact Finish Tin
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 2.54mm
PCB Contact Pattern RECTANGULAR
Body Breadth 0.736 inch
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 1A
Contact Style IDC
Insulation Resistance 1000000000Ohm
Row Spacing 0.600 (15.24mm)
Body/Shell Style PLUG
Dielectric Withstanding Voltage 500VAC V
Contact Pattern RECTANGULAR
Cable Termination IDC
Contact Current Rating 1A
Board-Side Pitch 0.100 2.54mm
Dimensions
Length 38.1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
