CPS16-NC00A10-SNCSNCNF-RI0BRVAR-W1031-S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPST-NC 100MA 42V
PDF
/
Inventory: 10037
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 28.5mm
Technical
Contact Voltage(DC)-Max 60V
Sealing CORROSION PROOF; IK09; IP67
Illumination Type, Color LED, Blue/Red
Illumination Voltage (Nominal) 5V~28VDC
Contact Current(DC)-Max 0.1A
Color - Actuator/Cap Silver
Panel Cutout Dimensions Circular - 16.10mm Dia
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Round, Button, Flush
Body Length or Diameter 14.7mm
Voltage - Rated AC 42V
Termination Style Wire Leads
Ingress Protection IP67 - Dust Tight, Waterproof
Current Rating (Amps) 100mA AC/DC
Voltage - Rated DC 60V
Type Capacitive, Illuminated
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature 4 Symbol
Series CPS
Packaging Bulk
Operating Temperature -40°C~60°C
Physical
Mounting Feature PANEL MOUNT-THREADED
Surface Mount NO
Mounting Type Panel Mount, Front
