Schurter Inc.
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description SWITCH PUSH SPST-NO 125MA 48V
PDF
/
Inventory: 9579
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings Dust Tight, IP65, Water Resistant
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Length - Termination 0.197 inch
Body Height 5.4mm

Technical

Contact Bounce Time-Max 0.1ms
Contact (DC) Max Power Rating R Load 0.72VA@48VDC
Number of Switches 1
PCB Hole Count 2
Contact (DC) Max Rating R Load 0.125A@48VDC
Operating Force 3 N
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 48V
Throw Configuration SPST
Electrical Life 1,000,000 Cycles
Max Current Rating 125mA
Contact Current(DC)-Max 0.125A
Insulation Resistance 1000000Ohm
Contact Resistance 0.05mOhm
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Square, Button, Flush
Body Breadth 18 mm
Body Length or Diameter 18mm
Termination Style PC Pin
Current Rating 125mA
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating (Amps) 125mA DC
Voltage - Rated DC 48V
Type Standard
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Tactile Feedback
Series MCS18
Packaging Bulk
Operating Temperature -25°C~60°C

Physical

Weight 99.988768mg
Housing Material THERMOPLASTIC
Mounting Type Through Hole
Mount Panel, Through Hole
Contact Material Silver

Supply Chain

Factory Lead Time 13 Weeks
