A22-DB-01M
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPST-NC 10A 110V
PDF
/
Inventory: 3883
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Body Height 47mm
Technical
Contact Voltage(AC)-Max 110V
Contact Current(AC)-Max 10A
Mechanical Life 5,000,000 Cycles
Electrical Life 500,000 Cycles
Contact Voltage(DC)-Max 24V
Contact Current(DC)-Max 10A
Color - Actuator/Cap Black
Panel Cutout Dimensions Circular - 22.30mm Dia
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Square, Button, Full Guard
Body Breadth 30 mm
Body Length or Diameter 36mm
Voltage - Rated AC 110V
Termination Style Screw Terminal
Ingress Protection IP65 - Dust Tight, Oil and Water Resistant
Current Rating (Amps) 10A AC/DC
Voltage - Rated DC 24V
HTS Code 8536.50.90.35
Additional Feature Non-lighted (Square Type)
Type Standard
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series A22
Published 1998
Packaging Bulk
Operating Temperature -20°C~70°C
Physical
Mounting Feature PANEL MOUNT-THREADED
Surface Mount NO
Mounting Type Panel Mount, Front
