UB25NBKW015F-JB
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches LOW PROFILE PSHBTTN ILLMNTD/PC AND SLDR
PDF
/
Inventory: 5683
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Silver
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Package / Case 125
Housing Material Polyamide
Technical
Operating Temperature -25°C~50°C
Packaging Bulk
Published 2011
Series UB
Feature With Barrier
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Type Standard, Illuminated
Voltage - Rated DC 30V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Termination Style Solder Lug
Voltage - Rated AC 125V
Actuator Type Rectangular, Button
Circuit DPDT
Switch Function On-Mom
Panel Cutout Dimensions Rectangular - 22.40mm x 16.20mm
Color - Actuator/Cap Clear (White Filter/Diffuser)
Illumination Voltage (Nominal) 2.1VDC
Illumination Type, Color LED, Green
Electrical Life 10,000 Cycles
Mechanical Life 1,000,000 Cycles
Illumination Type LED
Illumination Color Green
Life (Cycles) 10000 cycles
Compliance
RoHS Status ROHS3 Compliant
