UB216KKW015F-2F
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Pushbutton Switches
Description
Switch Push Button ON ON SPDT Square Button 5A 250VAC 30VDC Alternate Contact Solder Lug Panel Mount
PDF
/
Buying Options
Total Price: USD $14.25
Unit Price: USD $14.250217
≥1 USD $14.250217
≥200 USD $5.515493
≥500 USD $5.321184
≥1000 USD $5.225342
Inventory: 5263
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Length 19mm
Technical
Life (Cycles) 10000 cycles
Illumination Type LED
Mechanical Life 200,000 Cycles
Max Voltage Rating (DC) 30V
Electrical Life 10,000 Cycles
Max Current Rating 5A
Max Voltage Rating (AC) 250V
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 2.1VDC
Color - Actuator/Cap Green
Panel Cutout Dimensions Square - 17.40mm2
Switch Function On-On
Circuit SPDT
Actuator Type Square, Button
Voltage - Rated AC 125V
Termination Style Solder Lug
Current Rating 5A
Depth 19mm
Current Rating (Amps) 5A AC/DC
Voltage - Rated DC 30V
Terminal Finish GOLD
Type Standard, Illuminated
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series UB2
Published 2011
Packaging Bulk
Operating Temperature -25°C~50°C
Physical
Actuator Material Polycarbonate
Housing Material Polyamide
Package / Case 125
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Material Silver
Supply Chain
Factory Lead Time 8 Weeks
