BB15AW-HC
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches 0.213" LONG STR LONG SPDT ON (ON) RED
PDF
/
Buying Options
Total Price: USD $4.76
Unit Price: USD $4.7608
≥1 USD $4.7608
≥10 USD $4.24776
≥100 USD $3.690984
≥500 USD $3.051787
Inventory: 33
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Dimensions
Width 6.8mm
Length 8.8mm
Height 13.1mm
Technical
Washability SOLVENT
Life (Cycles) 50000 cycles
Actuator Travel 1.0922 mm
Contact Function ON-(ON)
PCB Hole Count 8
Mechanical Life 50,000 Cycles
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 500VAC V
Color - Actuator/Cap Red
Insulation Resistance 500000000Ohm
Contact Resistance 0.05mOhm
Switch Function On-Mom
Circuit SPDT
Actuator Type Round, Button
Body Breadth 6.8072 mm
Voltage - Rated AC 28V
Termination Style PC Pin
Current Rating 100mA
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 28V
Power Rating 400mW
Type Standard
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Antistatic
JESD-609 Code e4
Series BB
Published 2010
Packaging Bulk
Operating Temperature -30°C~85°C
Physical
End Contact Material BRASS
Terminal Material BRASS
Center Contact Material PHOSPHOR BRONZE
Actuator Material POLYACETAL
Housing Material Polyamide
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 5 Weeks
